Specifications
Voltage Rating
230V
Phase
Single Phase
Series
CPHS Series
Material
Cast Iron
Includes
Pump, Motor, Pressure Switch, Shallow Well Ejector
Item
Pump
Type
Centrifugal Pump
Number of Stages
1
Weight
50 lb.
Dimensions
24 in. x 12 in. x 12 in.
Power Source
Electric
Amperage Rating
10 Amps
Speed
3,450 RPM
Flow Rate
1,030 GPH
Wire Count
3
Inlet Connection
FNPT
Check Valve
No
Operating Pressure
50 PSI
Inlet Size
1-1/4 in.
Outlet Size
3/4 in.
Outlet Connection
FNPT
Cord Length
6 ft.
Vertical Lift
25 ft.
Pump Switch
Pressure
Working Temperature
100 F
Regulated
No
Brand Name
Flint & Walling
