Specifications
Voltage Rating
230v
Phase
Single-Phase
HP Rating
10 hp
Series
B Series
Material
Composite
Includes
Motor, Impeller, Mechanical Shaft Seal
Item
Pump
Type
Centrifugal
Number of Stages
1
Weight
200 lb.
Dimensions
12-3/8 in. x 10 in. x 23-4/5 in.
Power Source
Electric
Amperage Rating
46 Amps
Speed
3,600 RPM
Flow Rate
202 GPM
Inlet Connection
NPT
Operating Pressure
88 PSI
Inlet Size
2 in.
Outlet Size
1-1/2 in.
Outlet Connection
NPT
Vertical Lift
204 ft.
Working Temperature
180 F
Regulated
No
Brand Name
Berkeley
