Specifications
Voltage Rating
230v
Phase
Single-Phase
HP Rating
7.5 hp
Series
B Series
Material
Cast Iron, Bronze
Includes
Motor, Impeller, Mechanical Shaft Seal
Item
Pump
Type
Centrifugal
Number of Stages
1
Weight
49 lb.
Dimensions
20-3/4 in. x 12-3/8 in. x 10 in.
Power Source
Electric
Amperage Rating
32 Amps
Speed
3,600 RPM
Flow Rate
90 GPM
Inlet Connection
NPT
Operating Pressure
106 PSI
Inlet Size
1-1/2 in.
Outlet Size
1 in.
Outlet Connection
NPT
Vertical Lift
210 ft.
Working Temperature
200 F
Regulated
No
Brand Name
Berkeley
