Specifications
Voltage Rating
115v - 230v
Phase
Single Phase
HP Rating
2.5 hp
Series
LTH Series
Material
Cast Iron & Silicon Bronze
Includes
Self-Priming
Item
Pump
Type
Centrifugal
Number of Stages
1
Weight
95 lb.
Dimensions
24 in. x 18 in. x 16 in.
Power Source
Electric
Amperage Rating
12 Amps - 26 Amps
Speed
3,450 RPM
Flow Rate
162 GPM
Wire Count
3
Inlet Connection
FNPT
Check Valve
Yes
Operating Pressure
100 psi
Inlet Size
2 in.
Outlet Size
2 in.
Outlet Connection
FNPT
Cord Length
6 ft.
Vertical Lift
20 ft.
Pump Switch
Automatic
Working Temperature
140 F
Regulated
No
Brand Name
Berkeley
