Specifications
Voltage Rating
208v - 460v
Phase
Three-Phase
HP Rating
3 hp
Series
LTH Series
Material
Cast Iron
Includes
Self-Priming
Item
Pump
Type
Centrifugal
Number of Stages
1
Weight
144 lb.
Dimensions
20-3/4 in. x 9-1/2 in. x 13-1/4 in.
Power Source
Electric
Amperage Rating
4.3 Amps - 8.6 Amps
Speed
3,450 RPM
Flow Rate
162 GPM
Inlet Connection
Npt
Operating Pressure
100 psi
Inlet Size
2 in.
Outlet Size
1-1/2 in.
Outlet Connection
Npt
Vertical Lift
25 ft.
Working Temperature
140 F
Regulated
No
Brand Name
Berkeley
