Specifications
Voltage Rating
230v
Phase
Single Phase
HP Rating
3 HP
Series
LTH Series
Material
Cast Iron
Includes
Pump, Manual
Item
Pump
Type
Centrifugal
Number of Stages
1
Weight
144 lb.
Dimensions
20-3/4 in. x 9-1/2 in. x 13-1/4 in.
Power Source
Electric
Amperage Rating
15 Amps
Speed
3,450 RPM
Flow Rate
120 GPM
Wire Count
3
Inlet Connection
Flange
Check Valve
No
Operating Pressure
100 PSI
Inlet Size
2 in.
Outlet Size
1-1/2 in.
Outlet Connection
FNPT
Cord Length
6 ft.
Vertical Lift
5 ft.
Pump Switch
No Switch
Working Temperature
140 F
Regulated
No
Brand Name
Berkeley
