Specifications
Voltage Rating
115v - 230v
Phase
Three-Phase
HP Rating
5 hp
Series
LTH Series
Material
Cast Iron
Includes
Self-Priming
Item
Pump
Type
Centrifugal
Number of Stages
1
Weight
142 lb.
Dimensions
21-3/4 in. x 9-1/2 in. x 13-1/4 in.
Power Source
Electric
Amperage Rating
13.2 Amps - 6.6 Amps
Speed
3,450 RPM
Flow Rate
95 GPM
Inlet Connection
NPT
Operating Pressure
100 PSI
Inlet Size
2 in.
Outlet Size
1-1/2 in.
Outlet Connection
NPT
Vertical Lift
25 ft.
Working Temperature
104 F
Regulated
No
Brand Name
Berkeley
