Specifications
Voltage Rating
230v
Phase
Single Phase
HP Rating
2.5 HP
Series
J Series
Material
Cast Iron
Includes
Replaceable Wear Ring, Feature Back Pull-Out Design
Item
Pump
Type
Centrifugal
Number of Stages
1
Weight
74 lb.
Dimensions
17-3/4 in. x 9 in. x 8-5/8 in.
Power Source
Electric
Amperage Rating
15 Amps
Speed
3,450 RPM
Flow Rate
92 GPM
Wire Count
3
Inlet Connection
Fnpt
Check Valve
No
Operating Pressure
140 psi
Inlet Size
2 in.
Outlet Size
1-1/2 in.
Outlet Connection
Fnpt
Cord Length
6 ft.
Vertical Lift
25 ft.
Pump Switch
No Switch
Working Temperature
140 F
Regulated
No
Brand Name
Sta-Rite
