Specifications
Voltage Rating
230v
Phase
Single Phase
HP Rating
1 HP
Series
J Series
Material
Cast Iron
Includes
Replaceable Wear Ring, Feature Back Pull-Out Design
Item
Pump
Type
Centrifugal
Number of Stages
1
Weight
45 lb.
Dimensions
12-25/32 in. x 9 in. x 7 in.
Power Source
Electric
Amperage Rating
10 Amps
Speed
3,600 RPM
Flow Rate
62 GPM
Wire Count
3
Inlet Connection
Fnpt
Check Valve
No
Operating Pressure
100 psi
Inlet Size
1-1/4 in.
Outlet Size
1 in.
Outlet Connection
Fnpt
Cord Length
6 ft.
Vertical Lift
25 ft.
Pump Switch
No Switch
Working Temperature
140 F
Regulated
No
Brand Name
Sta-Rite
