Specifications
Voltage Rating
230v
Phase
Single Phase
HP Rating
5 HP
Series
PCA Series
Material
Composite
Includes
Pump, Manual, Warranty
Item
Pump
Type
Centrifugal
Number of Stages
1
Weight
75 lb.
Dimensions
16-7/8 in. x 12-3/4 in.
Power Source
Electric
Amperage Rating
17.6 Amps
Speed
3, 450 RPM
Flow Rate
19, 740 GPH
Wire Count
3
Inlet Connection
FNPT
Check Valve
Yes
Operating Pressure
50 PSI
Inlet Size
3 in.
Outlet Size
3 in.
Outlet Connection
FNPT
Cord Length
10 ft.
Vertical Lift
5 ft.
Pump Switch
Automatic
Working Temperature
100 F
Regulated
No
Brand Name
Easy Pro
