Specifications
Voltage Rating
460v
Phase
Three Phase
HP Rating
3 HP
Series
SPM Series
Material
Cast Iron
Includes
Pump, User Manual
Item
Pump
Type
Centrifugal
Number of Stages
1
Weight
130 lb.
Dimensions
24 in. x 18 in. x 18 in.
Power Source
Electric
Amperage Rating
15 Amps
Speed
3,450 RPM
Flow Rate
150 GPM
Wire Count
3
Inlet Connection
Flange
Check Valve
Yes
Operating Pressure
120 psi
Inlet Size
2 in.
Outlet Size
2-1/2 in.
Outlet Connection
Flange
Cord Length
6 ft.
Vertical Lift
20 ft.
Pump Switch
No Switch
Working Temperature
200 F
Regulated
No
Brand Name
Flint & Walling
