Specifications
Voltage Rating
230v
Phase
Single Phase
HP Rating
3 HP
Series
CJ101 Series
Material
Cast Iron
Includes
Tap, Plug, Vacuum Tapping, Drain Plug
Item
Pump
Type
Centrifugal
Number of Stages
3
Weight
85 lb.
Dimensions
24 in. x 18 in. x 15 in.
Power Source
Electric
Amperage Rating
13.5 Amps
Speed
3,450 RPM
Flow Rate
3,400 GPH
Wire Count
3
Inlet Connection
Fnpt
Check Valve
No
Operating Pressure
90 psi
Inlet Size
1-1/2 in.
Outlet Size
1-1/4 in.
Outlet Connection
Fnpt
Cord Length
6 ft.
Vertical Lift
25 ft.
Pump Switch
No Switch
Working Temperature
160 F
Regulated
No
Brand Name
Flint & Walling
