Specifications
Voltage Rating
230v
Phase
Single Phase
HP Rating
1.5 hp
Series
CJ101 Series
Material
Cast Iron
Includes
Plastic Impeller, Drain Plug, Tap, Plug, Vacuum Tapping
Item
Pump
Type
Centrifugal
Number of Stages
2
Weight
50 lb.
Dimensions
12 in. x 15 in. x 10 in.
Power Source
Electric
Amperage Rating
10.5 Amps - 21 Amps
Speed
3,450 RPM
Flow Rate
3,400 GPH
Wire Count
3
Inlet Connection
FNPT
Check Valve
No
Operating Pressure
90 psi
Inlet Size
1-1/2 in.
Outlet Size
1-1/4 in.
Outlet Connection
FNPT
Cord Length
6 ft.
Vertical Lift
25 ft.
Pump Switch
No Switch
Working Temperature
160 F
Regulated
No
Brand Name
Flint & Walling
