Specifications
Voltage Rating
230v
Phase
Single Phase
HP Rating
1 HP
Series
CJ103 Series
Material
Cast Iron
Includes
Drain Plug
Item
Pump
Type
Centrifugal
Number of Stages
1
Weight
50 lb.
Dimensions
14-1/2 in. x 8-1/4 in. x 9-1/2 in.
Power Source
Electric
Amperage Rating
18 Amps - 9 Amps
Speed
3,450 RPM
Flow Rate
3,400 GPH
Wire Count
3
Inlet Connection
FNPT
Check Valve
No
Operating Pressure
45 PSI
Inlet Size
1-1/2 in.
Outlet Size
1-1/4 in.
Outlet Connection
FNPT
Cord Length
6 ft.
Vertical Lift
25 ft.
Pump Switch
No Switch
Working Temperature
200 F
Regulated
No
Brand Name
Flint & Walling
