Specifications
Voltage Rating
115v - 230v
Phase
Single-Phase
HP Rating
1 hp
Series
Ek Series
Material
Composite
Includes
Pressure Switch, Shallow Well Ejector
Item
Pump
Type
Jet
Number of Stages
1
Weight
28.3 lb.
Dimensions
19-1/2 in. x 15-3/10 in. x 10-3/5 in.
Power Source
Electric
Amperage Rating
2.0 Amps
Speed
3,450 RPM
Flow Rate
19.5 GPM
Inlet Connection
Fnpt
Operating Pressure
150 psi
Inlet Size
1-1/4 in.
Outlet Size
3/4 in.
Outlet Connection
Fnpt
Vertical Lift
25 ft.
Working Temperature
148 F
Regulated
No
Brand Name
Flint & Walling
