Specifications
Voltage Rating
230v
Phase
Single Phase
HP Rating
3 HP
Series
SPJ Series
Material
Cast Iron
Includes
Self-Priming Brass Impeller
Item
Pump
Type
Centrifugal
Number of Stages
1
Weight
79 lb.
Dimensions
18-1/8 in. x 8-3/4 in. x 11-1/4 in.
Power Source
Electric
Amperage Rating
13.5 Amps
Speed
3,450 RPM
Flow Rate
88 GPM
Wire Count
3
Inlet Connection
Fnpt
Check Valve
No
Operating Pressure
100 psi
Inlet Size
2 in.
Outlet Size
1-1/2 in.
Outlet Connection
Fnpt
Cord Length
6 ft.
Vertical Lift
25 ft.
Pump Switch
No Switch
Working Temperature
180 F
Regulated
No
Brand Name
Flint & Walling
