FX Luminaire Cora CW-51 ZD Wall Wash 5W 2700K 35° Bronze CW51ZD35WFLAB

FX Luminaire Cora CW-51 ZD Wall Wash 5W 2700K 35° Bronze CW51ZD35WFLAB

FX
CW51ZD35WFLAB
$189.99
$189.99
Sale Sold out
Shipping calculated at checkout.

Highlights

Housing Material
Brass
Voltage Rating
10V - 15V
Average Life
30, 000 hrs.
Dimmable
Yes
Equivalent Wattage
35W
Includes
Large Slot Spike

Compatibility Notice

It is the buyer’s responsibility to confirm product compatibility with their system, application, and any local code requirements prior to purchase. Buyers should verify model numbers, specifications, sizing, and pressure ratings before ordering.
If you are unsure, you may contact us before purchasing and we will help confirm compatibility.

To initiate a return, customers must contact us before sending the item back. Unauthorized returns may be refused.

Return Policy

We accept returns within 14 days from your delivery date.

All returns are subject to a restocking fee. The restocking fee varies by product category and will be deducted from the refund amount.

Items must be unused, uninstalled, and returned in their original packaging. Products that show signs of use, installation, or damage are not eligible for return.

Return shipping costs are the responsibility of the customer unless the item arrives defective or incorrect. Original shipping charges are non-refundable.

To initiate a return, customers must contact us before sending the item back. Unauthorized returns may be refused.

If you’re unsure about fit, compatibility, or application, contact us prior to purchasing.

Description

The ZD version of the CW-51 adds zoning and dimming to FX Luminaire's wall wash fixture. Paired with a Luxor controller it joins a zone and dims on command, which lets a long facade sit at full output for an event and drop back to a low glow on ordinary nights. Be clear before ordering: without a Luxor controller you get a capable 5 watt wall wash and none of the ZD behavior, so the premium only makes sense inside a Luxor system. The fixture itself is select brass with black oxide stainless hardware and a fully potted interior, rated IP65 for coastal work, with an OptiClear frosted tempered glass lens that smooths the beam across a wall instead of leaving hot spots. The head adjusts in nine degree steps and locks under compression. Ships with the MR-16 ZD lamp, a ten foot lead and the ABS slotted spike. A low voltage transformer is required and sold separately.



View full details

Specifications

Finish Bronze
Length 4-2/5 in.
Mounting Ground Mount
Height 6-1/5 in.
Housing Material Brass
Dimmable Yes
Type Accent & Up
Includes Large Slot Spike
Number of Lamps 1 Lamp
Lead Wire Length 10 ft.
Volt-Ampere Rating 5.4 VA
Item Light Fixtures
Series CW-51 Series
Voltage Rating 10V - 15V
Bulb Shape MR16
Wire Size 18 AWG
Equivalent Wattage 35W
Dimensions 6-1/5 in. x 3-1/2 in. x 4-2/5 in.
Lamp Type MR16
Wattage 5W
Lighting Technology LED
Light Color Warm White
Color Temperature 2700K
Average Life 30, 000 hrs.
Wire Length 10 ft.
Socket Type GU5.3
Regulated No
Brand Name FX
