Specifications
Finish
Copper
Integrated/Drop-in
Integrated
Item
Light Fixtures
Type
Path & Area
Series
DP Series
Voltage Rating
10V - 15V
Bulb Shape
T3
Equivalent Wattage
20W
Length
12 in.
Dimensions
13-1/2 in. x 2-8/9 in.
Height
13-1/2 in.
Lamp Type
Bi-Pin
Dimmable
Yes
Number of Lamps
1
Wattage
1.6W
Lighting Technology
LED
Color Rendering Index (CRI)
80
Light Color
Warm White
Light Output
200 Lumens
Efficiency
125 Lumens/W
Color Temperature
3000K
Average Life
50, 000 hrs.
Beam Angle
Flood (41°–60°)
Maximum Overall Length
13-1/2 in.
Maximum Overall Diameter
2-8/9 in.
Bulb Spacing
12 in.
Material
Copper
Includes
Fixture, Specified Lamp Option, Specified Riser
Housing Material
Copper
Regulated
No
Brand Name
FX
