Specifications
Voltage Rating
115v - 230v
Phase
Single-Phase
HP Rating
1.5 hp
Series
IRRI-GATOR Series
Material
Cast Iron
Includes
Motor, Impeller
Item
Pump
Type
Centrifugal
Number of Stages
1
Weight
60 lb.
Dimensions
21-3/16 in. x 8-1/4 in. x 9-1/4 in.
Power Source
Electric
Amperage Rating
10 Amps - 20 Amps
Speed
3,500 RPM
Flow Rate
63 GPM
Inlet Connection
NPT
Operating Pressure
125 PSI
Inlet Size
1-1/2 in.
Outlet Size
1-1/2 in.
Outlet Connection
NPT
Vertical Lift
25 ft.
Working Temperature
140 F
Regulated
No
Brand Name
Goulds
