Hunter I-20 Adjustable Rotor 4 in. Riser with Check Valve and Pressure Regulated Body | I2004PRB
Hunter I-20 Adjustable Rotor 4 in. Riser with Check Valve and Pressure Regulated Body | I2004PRB
SKU:
I2004PRB
Regular price
$25.82
Regular price
Sale price
$25.82
Unit price
/
per
Couldn't load pickup availability
- Factory installed rubber cover for superior protection
- Quick check arc mechanism makes arc adjust fast and easy
- Pressure Regulated Body: Reduces high incoming pressure to prevent misting and allows nozzles to operate at peak efficiency, lower pressure produces larger water droplets that fight the effects of wind
- Drain check...
- Factory installed rubber cover for superior protection
- Quick check arc mechanism makes arc adjust fast and easy
- Pressure Regulated Body: Reduces high incoming pressure to prevent misting and allows nozzles to operate at peak efficiency, lower pressure produces larger water droplets that fight the effects of wind
- Drain check valve: The drain check valve keeps lines from draining when the system is shut off. This saves water, reduces liability and increases system life
- Automatic arc return, this patented feature returns the turret to the original arc regardless of where it is turned, This ensures vandal protection in any environment
- Flostop control: FloStop closes the flow of water from individual sprinkler heads while the system is running. This is ideal for changing nozzles or turning off specific heads during maintenance and construction
With 34 nozzle choices, a 17 ft. to 46 ft. radius, and 6 body choices, the I-20 is an indispensable rotor. Whether you’ve got a small area, sandy soil, or a mix of shrubs and grass, the I-20 is ready to water with efficiency and reliability. Recent improvements include automatic arc return, non-reversing 360, from 50 to 360 degrees, and a non-strippable, vandal-proof drive mechanism that prevents gear stripping and saves repair costs. Adding FloStop control, easy through-the-top arc adjustment, and a standard drain-check valve all equate to a rotor that stands second-to-none in its class.
Key Features
Key Features
Item: Rotor
Connection Type: Fnpt
Connection Size: 3/4 in.
Operating Radius: 17 ft. - 46 ft.
Inlet Connection: 3/4 in. FNPT
Adjustable Rotation Angle: 50 Degree - 360 Degree
Pop-Up Height: 4 in. Riser
Full-Circle/Part-Circle: Full Circle & Part Circle
Case Material: Plastic
Type: Adjustable
Series: I-20 Series
Pressure Regulating: Yes
Check Valve: Yes
Height: 11-1/8 in.
Riser Material: Plastic
Body Material: Plastic
Color: Black, Blue
Exposed Diameter: 1-3/4 in.
Maximum Operating Pressure: 100 PSI
Regulated: No
Brand Name: Hunter
