Specifications
Voltage Rating
115V - 230V
Phase
Single-Phase
HP Rating
1.5 HP
Series
JS+ Series
Material
Composite
Includes
Motor, Pressure Switch, Plug
Item
Pump
Type
Jet
Number of Stages
1
Weight
38 lb.
Dimensions
8-3/4 in. x 9-7/8 in. x 19-1/4 in.
Power Source
Electric
Amperage Rating
14 Amps
Speed
3,500 RPM
Flow Rate
26 GPM
Inlet Connection
NPT
Operating Pressure
50 PSI
Inlet Size
1-1/4 in.
Outlet Size
1 in.
Outlet Connection
NPT
Vertical Lift
25 ft.
Working Temperature
140 F
Regulated
No
