Specifications
Voltage Rating
115v - 230v
Phase
Single-Phase
HP Rating
1 hp
Series
HJ Series
Material
Composite
Includes
Motor, Pressure Switch, Impeller
Item
Pump
Type
Jet
Number of Stages
1
Weight
54.5 lb.
Dimensions
19-2/5 in. x 10-2/9 in. x 8-5/7 in.
Power Source
Electric
Amperage Rating
17 Amps - 8.5 Amps
Speed
3,500 RPM
Flow Rate
27.5 GPM
Inlet Connection
NPT
Operating Pressure
67 PSI
Inlet Size
1-1/4 in.
Outlet Size
1 in.
Outlet Connection
NPT
Vertical Lift
20 ft.
Working Temperature
140 F
Regulated
No
Brand Name
Myers
