Specifications
Voltage Rating
115v - 230v
Phase
Single-Phase
HP Rating
0.50 hp
Series
HR Series
Material
Composite
Includes
Motor, Pressure Switch, Impeller
Item
Pump
Type
Jet
Number of Stages
1
Weight
40 lb.
Dimensions
17-1/4 in. x 9-2/3 in. x 8-1/3 in.
Power Source
Electric
Amperage Rating
9.4 Amps - 4.7 Amps
Speed
3,500 RPM
Flow Rate
11.5 GPM
Inlet Connection
Npt
Operating Pressure
70 psi
Inlet Size
1-1/4 in.
Outlet Size
1 in.
Outlet Connection
Npt
Vertical Lift
20 ft.
Working Temperature
140 F
Regulated
No
Brand Name
Myers
