Specifications
Voltage Rating
230v
Phase
Single Phase
HP Rating
1 HP
Series
IKON10 Series
Material
Stainless Steel
Includes
Motor
Item
Pump
Type
Constant Pressure System
Number of Stages
1
Weight
21.61 lb.
Dimensions
24 in. x 12 in. x 12 in.
Power Source
Electric
Amperage Rating
2.8 Amps - 5.6 Amps
Speed
3, 600 RPM
Flow Rate
10 GPM
Wire Count
3
Inlet Connection
FNPT
Check Valve
Yes
Operating Pressure
120 PSI
Inlet Size
1 in.
Outlet Size
1 in.
Outlet Connection
FNPT
Cord Length
6 ft.
Vertical Lift
20 ft.
Pump Switch
Pressure
Working Temperature
140 F
Regulated
No
Brand Name
PD Water Systems
