Specifications
Voltage Rating
230v
Phase
Single Phase
HP Rating
2 HP
Series
IKON20 Series
Material
Stainless Steel
Includes
Pump, Manual, Installation Kit
Item
Pump
Type
Constant Pressure System
Number of Stages
1
Weight
28 lb.
Dimensions
17-1/3 in. x 9-1/4 in. x 5-3/4 in.
Power Source
Electric
Amperage Rating
5.9 Amps
Speed
3, 600 RPM
Flow Rate
20 GPM
Wire Count
3
Inlet Connection
FNPT
Check Valve
Yes
Operating Pressure
120 PSI
Inlet Size
1 in.
Outlet Size
1 in.
Outlet Connection
FNPT
Cord Length
6 ft.
Vertical Lift
20 ft.
Pump Switch
Automatic
Working Temperature
140 F
Regulated
No
Brand Name
PD Water Systems
