Specifications
Voltage Rating
230v
Phase
Single Phase
HP Rating
1 HP
Series
IRON JET Series
Material
Cast Iron
Includes
Drain Plug, Motor
Item
Pump
Type
Jet
Number of Stages
1
Weight
69 lb.
Dimensions
24 in. x 12 in. x 12 in.
Power Source
Electric
Amperage Rating
16.6 Amps - 8.3 Amps
Speed
3,450 RPM
Flow Rate
10 GPM
Wire Count
3
Inlet Connection
FNPT
Check Valve
No
Operating Pressure
125 PSI
Inlet Size
1-1/4 in.
Outlet Size
1 in.
Outlet Connection
FNPT
Cord Length
6 ft.
Vertical Lift
25 ft.
Pump Switch
Pressure
Working Temperature
150 F
Regulated
No
Brand Name
Pearl
