Specifications
Voltage Rating
230v
Phase
Single Phase
HP Rating
1 HP
Series
DS3 Series
Material
Cast Iron
Includes
Pump, Manual, Installation Instructions
Item
Pump
Type
Centrifugal
Number of Stages
1
Weight
52 lb.
Dimensions
17 in. x 13-1/9 in. x 10 in.
Power Source
Electric
Amperage Rating
10 Amps
Speed
3,450 RPM
Flow Rate
61 GPM
Wire Count
3
Inlet Connection
FNPT
Check Valve
No
Operating Pressure
60 PSI
Inlet Size
2 in.
Outlet Size
1-1/2 in.
Outlet Connection
FNPT
Cord Length
6 ft.
Vertical Lift
25 ft.
Pump Switch
No Switch
Working Temperature
140 F
Regulated
No
Brand Name
Sta-Rite
