Specifications
Connection Type
Fipt
Connection Size
1-1/2 in.
Body Material
Plastic
Type
In-Line
Check Valve
No
Series
IVM Series
Pressure Regulating
Yes
Solenoid Type
50/60 Hz Solenoid
Operating Type
Electric
Flow Control
Yes
InletSize
1-1/2 in.
Height
8 in.
Width
6-3/4 in.
Maximum Flow Rate
150 GPM
Voltage Rating
120V
Outlet Size
1-1/2 in.
Minimum Flow Rate
2 GPM
Outlet Connection
Fipt
Depth
3-1/2 in.
Inlet Connection
Fipt
Pressure Rating
15 PSI - 150 PSI
Item
Electric Valve
Dimensions
3-1/2 in. x 6-3/4 in. x 8 in.
Minimum Operating Pressure
15 PSI
Maximum Operating Pressure
150 PSI
Maximum Working Temperature
110 F
Connection 2 Size
1-1/2 in.
Connection 2 Type
Fipt
Regulated
No
Brand Name
Rain Bird
