Specifications
Voltage Rating
230v
Phase
Single Phase
HP Rating
1-1/2 hp
Series
DS2 Series
Material
Cast Iron
Includes
Pump, Manual, Installation Instructions
Item
Pump
Type
Centrifugal
Number of Stages
1
Weight
79 lb.
Dimensions
17-5/6 in. x 10-2/7 in. x 13 in.
Power Source
Electric
Amperage Rating
19.2 Amps - 9.6 Amps
Speed
3,450 RPM
Flow Rate
70 GPM
Wire Count
3
Inlet Connection
FNPT
Check Valve
No
Operating Pressure
50 psi
Inlet Size
2 in.
Outlet Size
1-1/2 in.
Outlet Connection
FNPT
Cord Length
6 ft.
Vertical Lift
25 ft.
Pump Switch
No Switch
Working Temperature
100 F
Regulated
No
Brand Name
Sta-Rite
