Specifications
Voltage Rating
230v
Phase
Single Phase
HP Rating
1 HP
Series
MS Series
Material
Cast Iron
Includes
Pre-Plumbed External Automatic Regulator
Item
Pump
Type
Jet
Number of Stages
19
Weight
73 lb.
Dimensions
24 in. x 12 in. x 12 in.
Power Source
Electric
Amperage Rating
15 Amps
Speed
3,600 RPM
Flow Rate
30 GPM
Wire Count
3
Inlet Connection
Fnpt
Check Valve
No
Operating Pressure
60 psi
Inlet Size
1-1/4 in.
Outlet Size
1 in.
Outlet Connection
Fnpt
Cord Length
6 ft.
Vertical Lift
20 ft.
Pump Switch
Pressure
Working Temperature
100 F
Regulated
No
Brand Name
Sta-Rite
