Specifications
Voltage Rating
230v
Phase
Single Phase
HP Rating
1 HP
Series
SN Series
Material
Cast Iron
Includes
Pump, Manual, Installation Instructions
Item
Pump
Type
Jet
Number of Stages
1
Weight
55 lb.
Dimensions
21-2/7 in. x 9-15/32 in. x 9-17/31 in.
Power Source
Electric
Amperage Rating
15 Amps
Speed
3,600 RPM
Flow Rate
23 GPM
Wire Count
3
Inlet Connection
FNPT
Check Valve
No
Operating Pressure
50 PSI
Inlet Size
1-1/4 in.
Outlet Size
1 in.
Outlet Connection
FNPT
Cord Length
6 ft.
Vertical Lift
25 ft.
Pump Switch
Pressure
Working Temperature
140 F
Regulated
No
Brand Name
Sta-Rite
