Specifications
Voltage Rating
230v
Phase
Single Phase
HP Rating
3/4 HP
Series
SN Series
Material
Cast Iron
Includes
Pump, Manual, Installation Instructions
Item
Pump
Type
Jet
Number of Stages
1
Weight
47 lb.
Dimensions
18-5/7 in. x 9-15/32 in. x 9-17/31 in.
Power Source
Electric
Amperage Rating
10 Amps
Speed
3,600 RPM
Flow Rate
15 GPM
Wire Count
3
Inlet Connection
Fnpt
Check Valve
No
Operating Pressure
50 psi
Inlet Size
1-1/4 in.
Outlet Size
1 in.
Outlet Connection
Fnpt
Cord Length
6 ft.
Vertical Lift
25 ft.
Pump Switch
Pressure
Working Temperature
140 F
Regulated
No
Brand Name
Sta-Rite
