Specifications
Voltage Rating
115v - 230v
Phase
Single-Phase
HP Rating
1 hp
Series
HQ Series
Material
Composite
Includes
Motor, Pump, Electronic Control
Item
Motor
Type
Submersible
Number of Stages
1
Weight
23.8 lb.
Dimensions
16-1/9 in. x 8-5/8 in. x 7-2/7 in.
Power Source
Electric
Amperage Rating
10 Amps - 5 Amps
Speed
2, 850 RPM
Flow Rate
31.7 GPM
Inlet Connection
NPT
Operating Pressure
25 PSI
Inlet Size
1 in.
Outlet Size
1 in.
Outlet Connection
NPT
Vertical Lift
25 ft.
Working Temperature
104 F
Regulated
No
Brand Name
Walrus
